11" x 25" x 24" Four High Waterbury Farrel Cold Rolling Mill Manufacture Waterbury Farrel Material: Stanless Steel, Carbon Steel Material Width 6" Min. - 19" Max (152.4mm - 482.6mm) Material Thickness .035" Min. - .200" Max. (.899mm - 5.080mm) Cold Rolled Strip Coil OD: 47" Max. (1,193.80 mm) Coil ID 20" (508 mm) Coil Weight: 5760 Lbs. (2,612.690 kg) Uncoiler/Payoff Reel, Mandrel Type Diameter:      20 Inches (508.000 mm) Face:            21 Inches (533.400 mm) Gear Ratio:   20.2:1 Drive Motor: 100 HP (74.600 kw), 500-1200 Rpm, DC Mill Stand: Work Roll Diameter: 11 Inches (279.400 mm) Roll Face:                 24 Inches (609.600 mm) Bearing Type:           Roller   Back Up Rolls Diameter: 25 Inches (635.000 mm) Roll Face:                        24 Inches (609.600 mm) Bearing Type:                  Roller Drive Spindle Type:        Geared Pass Line:                      42 Inches (1,066.800 mm) Shoe / Sole Plate:          Yes Line Speed:                    200/300 FPM Pinion Stand Pitch Diameter: 11 Inches (279.400 mm) Horsepower:      500 HP (373.000 kw) Bearing Type:    Roller Reducer Mill Drive Type: Combination PS/GR Horsepower: 500 HP (373.000 kw) Input RPM: 350-1400 RPM Gear Ratio: 12.1:1 Bearing Type: Roller Approximate Weight:  17,500 Pounds Main Mill Motor 500 HP (373.000 kw), 350-1400 RPM, DC Roll Change: Manual Exit Tension Reel, Mandrel Type Horsepower: 150 HP (111.900 kw), 400-1000 Rpm, DC
